DISSOLVABLE PLUG

PRODUCT OVERVIEW

Dissolvable Frac Plug adopts high-strength fully dissolvable materials for temporary zonal isolation during staged fracturing of horizontal and vertical wells. This innovative tool is composed of soluble magnesium-aluminum alloy metal and soluble rubber sleeve, customizable to match diverse geological and construction demands. It delivers outstanding sealing isolation performance and achieves thorough dissolution rapidly in fresh water or low-concentration KCL brine under both high and low downhole temperatures. No post-operation milling or drilling is required after fracturing, leaving a full-bore wellbore, which greatly cuts rig time and operation costs for oil & gas well stimulation and re-completion work.

BENEFITS

• Rated to 10,000 psi at temperatures ranging from 77 to 248℉.
• Constructed of 100% dissolvable material, it can dissolve in low-salinity, low-temperature wells and fresh water wellbores.
• Fully dissolvable in a short period of time; no mill-out is required to remove the plug, saving rig time and costs.
• Features a large ID bore for increased flow-back after frac.
• Customizable dissolution time.
• Minimum-length design delivers faster dissolution and less material usage.
